design.md for a Tailwind + shadcn/ui Codebase

# product-name — design.md

> Canonical design memory for a Tailwind v4 + shadcn/ui codebase.
> Every AI session and human contributor reads this **before** writing UI.
> If a token, utility, or variant you need isn't here, propose adding it
> before reaching for an arbitrary value.

**Last updated**: YYYY-MM-DD
**Scope**: `src/`
**Source of truth for values**:
- CSS variables — `src/styles/globals.css` (`@theme` block)
- Primitives — `src/components/ui/*.tsx` (shadcn-generated)
- Variant recipes — colocated `*.variants.ts` next to each primitive
- Utility composition helper — `src/lib/utils.ts` (`cn()`)

This file documents how to **use** those values. Never duplicate a hex,
a px value, or a `cva()` block here. Reference the file.

## 1. Brand

| Surface | Value |
|---|---|
| Product | one-line product description |
| Audience | who this is for |
| Wordmark | how the name appears |
| Voice | how the product talks (3–5 traits, with bans) |
| References we draw from | 2–3 products we deliberately resemble |
| References we **avoid**  | 2–3 we deliberately don't resemble |

All colours are defined as CSS variables inside the `@theme` block in
`src/styles/globals.css`. Tailwind v4 reads them at build time and emits
the matching utilities (`bg-brand-500`, `text-brand-700`, etc.).

**Never hardcode hex values, OKLCH literals, or arbitrary colour utilities
(`bg-[#1234ab]`, `text-[oklch(...)]`).**

✅ `<div className="bg-brand-500 text-fg-on-brand">`
❌ `<div className="bg-[#1E40AF] text-[#fff]">`
❌ `<div style={{ background: '#1E40AF' }}>`

**Brand — deep blue** (`--color-brand-50` through `--color-brand-950`).
Source: `globals.css`. Used for navigation chrome, headlines, the
secondary CTA button. Not the primary CTA — see Section 2c.

| Token              | OKLCH               | Use |
|---|---|---|
| `--color-brand-50`  | oklch(0.97 0.02 250) | tinted backgrounds, info bg |
| `--color-brand-500` | oklch(0.55 0.18 250) | nav chrome, headlines, secondary-CTA bg |
| `--color-brand-700` | oklch(0.42 0.18 250) | hover-darker chrome, focused borders |
| `--color-brand-900` | oklch(0.25 0.10 250) | high-contrast text on tinted bg |

**Semantic tokens** — defined in `globals.css`, consumed by shadcn primitives.

| CSS var              | Tailwind utility            | Meaning |
|---|---|---|
| `--background`       | `bg-background`             | page surface (default white / dark) |
| `--foreground`       | `text-foreground`           | default body text |
| `--card`             | `bg-card`                   | elevated surface (cards, tables, sheets) |
| `--card-foreground`  | `text-card-foreground`      | text on card surfaces |
| `--popover`          | `bg-popover`                | popovers, dropdowns, menus |
| `--primary`          | `bg-primary text-primary-foreground` | **primary CTA** — see inversion below |
| `--secondary`        | `bg-secondary text-secondary-foreground` | secondary CTA |
| `--muted`            | `bg-muted text-muted-foreground` | de-emphasised surfaces, helper text |
| `--accent`           | `bg-accent text-accent-foreground` | hover surfaces, selected rows |
| `--destructive`      | `bg-destructive text-destructive-foreground` | delete, disconnect, irreversible |
| `--border`           | `border-border`             | every component border |
| `--input`            | `border-input`              | form field borders |
| `--ring`             | `ring-ring`                 | focus ring colour |
| `--radius`           | `rounded-md` / `rounded-lg` | base radius scalar |

> ⚠ **Critical convention**: in `globals.css`, `--primary` maps to the
> **accent** OKLCH scale, **not the brand scale**. The brand is wired to
> `--secondary`. This is intentional: the most committal action on any
> surface should be visually warm; the brand blue is reserved for chrome.
>
> Practical consequence: the shadcn `<Button>` with no props
> (`<Button>Save</Button>`) renders **warm-orange**, not brand-blue.
> An agent that pattern-matched `--primary === brand` will get every
> primary CTA wrong.

### Colour use — quick rules

- **Primary CTA on any surface**: `<Button>` (no `variant` prop). Exactly one per surface.
- **Secondary CTA**: `<Button variant="secondary">`.
- **Destructive action**: `<Button variant="destructive">`.
- **De-emphasised inline action**: `<Button variant="ghost">` or `variant="link"`.
- **Status communication**: `bg-success-50`, `bg-warning-50`, `bg-danger-50` for tinted-bg alerts.
  Never use brand or accent for status.
- **Hover row in a table**: `hover:bg-accent`. Never a custom grey.
- **Tinted info banner**: `bg-brand-50 text-brand-900 border border-brand-200`.
- **Gradients**: marketing + onboarding only. Never on data UI.

## 3. Typography

**Font family**: Inter, loaded via `next/font` (or the project's equivalent)
into `--font-sans`. Fallback: `ui-sans-serif, system-ui, sans-serif`.

**The scale is encoded as a CVA recipe**, not raw utilities, in
`src/components/ui/text.tsx`. Use `<Text variant="…">`; do not reach for
`text-* font-*` combinations inline.

| Variant     | Utility composition           | Use |
|---|---|---|
| `h1`        | `text-2xl font-normal tracking-tight` | page H1 (list page title, detail name) |
| `h2`        | `text-xl font-medium tracking-tight`  | section H2 |
| `cardTitle` | `text-base font-medium`               | card / sheet titles |
| `denseTitle`| `text-sm font-medium`                 | dense card titles, table-section headers |
| `body`      | `text-sm font-normal text-foreground` | **default body** — table rows, form fields |
| `caption`   | `text-xs font-normal text-muted-foreground` | metadata, timestamps, helper text |
| `overline`  | `text-xs font-medium uppercase tracking-wide text-muted-foreground` | section labels |

**Weights**: 400, 500. **No 600, no 700** for body — emphasis uses
weight 500 with a darker token, not heavier weight.

**Tabular numbers**: any column rendering money, quantity, or counts must
use `tabular-nums` (utility) or `font-variant-numeric: tabular-nums` on
the cell. Non-negotiable in tables.

## 4. Spacing

Sanctioned spacing utilities — every gap, margin, and padding in `src/`
must use one of these. The same eight values cover `gap-*`, `p-*`, `m-*`,
`space-y-*`, `space-x-*`.

| Utility | Px | Use |
|---|---|---|
| `gap-1`  | 4   | tightest gap (icon + label, chip internal) |
| `gap-2`  | 8   | dense table cells, small button padding |
| `gap-3`  | 12  | form field internal stacking |
| `gap-4`  | 16  | card sections, form rows |
| `gap-6`  | 24  | page header padding, between cards |
| `gap-8`  | 32  | between large sections |
| `gap-12` | 48  | top-of-page section break |
| `gap-16` | 64  | empty-state vertical centring |

**Standard combinations**:
- Between cards / form sections: `gap-6`
- Between fields inside a form: `gap-4`
- Inline (icon + label): `gap-2`
- Page outer padding: `px-6 py-4` on desktop, `px-4 py-3` on mobile

❌ **Banned**: arbitrary values (`gap-[19px]`), half-step utilities
(`gap-3.5`, `p-2.5`), odd-step utilities (`gap-5`, `gap-7`, `gap-9`,
`gap-11`).

## 5. Borders + radius

**Default border**: `border border-border` — every separator, card edge,
input outline.
**Subtle inner divider**: `border border-border/50` (50% opacity on
the same token).
**Focused border**: `focus-visible:ring-2 ring-ring ring-offset-2`.

**Radius** is driven by the `--radius` scalar in `globals.css`
(`0.5rem` by default). Tailwind derives `rounded-sm`, `rounded-md`,
`rounded-lg` from it.

| Utility       | Use |
|---|---|
| `rounded-sm`  | inputs, chips, small buttons |
| `rounded-md`  | buttons (default), cards, popovers |
| `rounded-lg`  | sheets, dialogs, page-wrapper cards |
| `rounded-full`| avatars, status dots, pill chips |

❌ **Banned**: arbitrary radii (`rounded-[7px]`), `rounded-xl` /
`rounded-2xl` / `rounded-3xl` on data UI.

## 6. Shadows

Tailwind's shadow scale (`shadow-sm` → `shadow-2xl`) is largely **not
used**. Surfaces are flat against `bg-muted/30` page fields.

| Utility    | Use |
|---|---|
| `shadow-sm`| primary buttons, cards on tinted bg |
| `shadow`   | popovers, dropdown menus, autocomplete |
| `shadow-md`| dialogs, sheets |

❌ **Banned on data UI**: `shadow-lg`, `shadow-xl`, `shadow-2xl`, any
coloured shadow (`shadow-brand-500/40`), any glow.

**Lint grep** (CI): `grep -rE 'shadow-(lg|xl|2xl)\b' src/` must return
zero hits outside `src/pages/(marketing|onboarding)/`.

### Button

```tsx
import { Button } from '@/components/ui/button';

<Button>Save</Button>                       // primary CTA
<Button variant="secondary">Cancel</Button>
<Button variant="destructive">Delete</Button>
<Button variant="ghost" size="sm">Reset</Button>


Three things to notice in this shape:

1. **Import path is explicit.** No alias guessing.
2. **The variant tables have "When" columns.** That is where the design memory lives.
3. **The bottom constraint** ("one primary per surface") is the rule that makes the system coherent.

### 7b. Form fields — `src/components/ui/*`

```markdown
### Form fields — decision table

| Scenario              | Primitive            | Path                                |
|---|---|---|
| Text / textarea       | `Input` / `Textarea` | `@/components/ui/input` `/textarea` |
| Single select         | `Select`             | `@/components/ui/select`            |
| Multi-select / combobox| `Combobox` (custom)  | `@/components/ui/combobox`          |
| Checkbox              | `Checkbox`           | `@/components/ui/checkbox`          |
| Toggle                | `Switch`             | `@/components/ui/switch`            |
| Radio group           | `RadioGroup`         | `@/components/ui/radio-group`       |
| Number / currency     | `NumberInput`        | `@/components/ui/number-input`      |
| Date picker           | `DatePicker`         | `@/components/ui/date-picker`       |

Every field is wrapped in shadcn `<Form>` + `<FormField>` + `<FormItem>` +
`<FormLabel>` + `<FormControl>` + `<FormMessage>`. See Section 13.

### Card

```tsx
import {
  Card, CardHeader, CardTitle, CardDescription,
  CardContent, CardFooter,
} from '@/components/ui/card';

<Card>
  <CardHeader>
    <CardTitle>Customer summary</CardTitle>
    <CardDescription>Updated 2 minutes ago</CardDescription>
  </CardHeader>
  <CardContent>...</CardContent>
  <CardFooter className="justify-end gap-2">
    <Button variant="ghost">Cancel</Button>
    <Button>Save</Button>
  </CardFooter>
</Card>


### 7d. Avatar, Table, Sheet, Dialog, Popover, EmptyState, Skeleton

```markdown
### Avatar — `@/components/ui/avatar`
Use `<Avatar><AvatarImage src=… /><AvatarFallback>{initials}</AvatarFallback></Avatar>`.
Fallback initials are required. Size: `h-8 w-8` (table rows), `h-10 w-10` (header).

### Table — `@/components/ui/table` + TanStack Table
The shadcn `Table` primitive renders the markup; TanStack provides the
state. See Section 15. Never use a bare `<table>` in `src/pages/`.

### Sheet — `@/components/ui/sheet`
Side drawer. Default `side="right"`. Use for forms with > 2 fields. See Section 17.

### Dialog — `@/components/ui/dialog`
Centered modal. Use only for confirmations of destructive actions, or
single-question prompts. See Section 17.

### Popover — `@/components/ui/popover`
Anchored floating panel. Use for filter menus, column pickers,
small inline editors. Width: `w-64` default, `w-80` for filter menus.

### EmptyState — `@/components/empty-state`
Custom (not shadcn). Centered icon (24px, `text-muted-foreground`),
H2 (`<Text variant="h2">`), one-line caption, optional `<Button size="lg">`.

### Skeleton — `@/components/ui/skeleton`
`<Skeleton className="h-N w-N" />` matching the dimensions of the
content it replaces. Per-row, per-field, per-card. Never a single
full-width skeleton on a list page.

### List page



- Outer shell: `flex flex-col h-full`.
- Header, toolbar, footer: `shrink-0`. Body: `flex-1 overflow-auto`.
- Reference: `src/pages/customers/list.tsx`.

### Sheet form (create / edit)



- Width: `w-[480px] sm:max-w-[480px]`. Wider only with a documented reason.
- Body: `flex-1 overflow-y-auto px-6 py-4 space-y-4`.
- Footer: `border-t px-6 py-3 justify-end gap-2`.
- Reference: `src/pages/customers/customer-sheet.tsx`.

### Detail page



- Container: `mx-auto max-w-6xl px-6 py-6`.
- Cards: `Card` primitive (Section 7c), never raw divs.
- Reference: `src/pages/customers/[id]/detail.tsx`.

## 9. Loading + transitions

### Rules

1. **Skeleton-match-layout**: skeletons match the exact dimensions of the
   content they replace. Per-row, per-card.
2. **No centered spinners** on list pages, forms, or detail pages.
3. **Optimistic mutations** with TanStack Query's `onMutate` where the
   API contract permits.
4. **Toast on async result**, not on user-initiated submits that already
   produce a UI change (e.g., row disappears).
5. **Pre-fetch on hover** for table-row → detail navigation via
   TanStack Query's `queryClient.prefetchQuery`.

### Banned

- ❌ Centered `<Loader2 className="animate-spin" />` as the only loading state.
- ❌ "Loading..." text alone.
- ❌ Slide / fade route transitions implemented in CSS keyframes.
- ❌ Full-page blocking spinners. Replace with optimistic UI or skeletons.

## 10. Anti-patterns (banned)

- ❌ **Arbitrary value escape hatches.** `text-[14px]`, `mt-[19px]`,
  `bg-[#1234ab]`, `gap-[15px]`. Use the token or propose a new one.
- ❌ **`@apply` directives** in CSS files. `@apply` re-introduces the
  cascade and defeats the linter. The one exception is `src/components/ui/*`
  base-layer resets — nowhere else.
- ❌ **Inline `className` strings longer than ~80 chars.** Extract to a
  CVA recipe (`*.variants.ts`) or to a component.
- ❌ **Bypassing `cn()`.** Never concatenate class names with `+` or
  template literals. Always pipe through `cn(...)` so `tailwind-merge`
  resolves conflicts.
- ❌ **Two `variant="default"` Buttons on the same surface.** Pick one.
- ❌ **Direct imports from `@radix-ui/*`** in `src/pages/` or `src/features/`.
  Always go through `src/components/ui/*`. The shadcn wrapper exists so
  styling, focus rings, and ARIA defaults stay consistent.
- ❌ **`!important` utilities** (`!bg-red-500`, `!mt-4`). Refactor the
  underlying class or selector. An `!` in a diff is an architectural smell.
- ❌ **Hex literals** anywhere in `className` or `style`. Including
  `text-[#666]`, `style={{ color: '#666' }}`.
- ❌ **`any` / `as any` / `@ts-ignore`.**
- ❌ **Default exports** in `src/components/`. Named exports only.
  shadcn-generated primitives already follow this; keep it consistent.
- ❌ **Cross-module imports.** `src/features/customers/*` cannot import
  from `src/features/invoices/*`. Lift to `src/components/` or `src/lib/`.
- ❌ **Icon barrel imports.** `import { ChevronDown, Trash } from 'lucide-react'`
  pulls the whole icon bundle into the chunk. Use the per-icon entry:
  `import { ChevronDown } from 'lucide-react/dist/esm/icons/chevron-down'`
  or a project `<Icon name="chevron-down" />` wrapper.

**Lint greps** (run in CI):

- Arbitrary values: `grep -rE '\b(text|p|m|gap|w|h|bg|border)-\[' src/`
- `@apply` outside ui base: `grep -rn '@apply' src/ | grep -v 'src/components/ui/'`
- Hex literals in className: `grep -rnE '#([0-9a-fA-F]{3}){1,2}' src/ | grep -v '\.svg'`
- `!important` utilities: `grep -rnE '\b!(bg|text|p|m)-' src/`

Each of these should be a non-zero finding the first time it runs and
zero on every commit after.

## 11. Empty states

Every list and every detail-page-tab needs an empty state. Use the
`EmptyState` component (Section 7d).

Slots: icon (`lucide-react`, 24px, `text-muted-foreground`), title
(`<Text variant="h2">`), description (one line, `text-muted-foreground`),
optional CTA (`<Button size="lg">`).

❌ No "No data" text alone. ❌ No illustrations on the data-UI surface.

## 12. Form patterns

- **Schema**: Zod in `src/features/<module>/schema.ts`, with inferred type
  (`type CustomerInput = z.infer<typeof customerSchema>`).
- **Required strings**: `z.string().min(1, '...')` — never `.nonempty()`
  (deprecated).
- **Nullable selects**: `.nullable().refine(v => v !== null, '...')`.
- **react-hook-form mode**: `'all'` (validate on blur and change).
- **Resolver**: `zodResolver(schema)` from `@hookform/resolvers/zod`.
- **Markup**: shadcn `<Form>` + `<FormField>` + `<FormItem>` + `<FormLabel>`
  + `<FormControl>` + `<FormMessage>`. Always all six.
- **Required indicator**: red asterisk inside `<FormLabel>`,
  `text-destructive`. Never parenthesised "(required)".
- **Submit button**: bottom-right of `SheetFooter` / `CardFooter`,
  `<Button type="submit">`.
- **Cancel**: only when context demands. `<Button variant="ghost">`.
- **Async submit**: `disabled={form.formState.isSubmitting}` with the
  loader pattern from Section 7a.

## 13. Tables

- **Markup**: shadcn `Table` primitive from `@/components/ui/table`.
- **State**: TanStack Table `useReactTable` in the page module.
- **Column defs**: colocated in `src/features/<module>/columns.tsx`.
- **Row height**: `h-12` (48px).
- **Cell padding**: `px-4 py-2`. The `Table` primitive already encodes this.
- **Header**: `bg-muted/50 text-muted-foreground font-medium text-xs uppercase`.
- **Row hover**: `hover:bg-accent`.
- **Selected row**: `data-[state=selected]:bg-accent/60`.
- **Sticky header**: wrap `<TableHeader>` in a `sticky top-0 z-10` div
  inside the scroll container.
- **Numeric columns**: `text-right tabular-nums`.
- **Action column**: last column, `w-12`, icon-only `<Button variant="ghost" size="icon">`.
- **Empty state**: see Section 11. Render via the `EmptyState` component, not
  a custom `<tr>`.

**Reference**: `src/pages/invoices/list.tsx` is the canonical implementation.

## 14. Toasts

- Library: `sonner`, mounted once in `src/app/layout.tsx` via `<Toaster />`.
- Position: `bottom-right`.
- Duration: success 3s, error 5s, info 4s. Sticky only for actionable errors.
- One line, plain text. No headlines. No HTML. No rich content.
- **Don't toast** on direct user actions that already produce a UI change
  (row disappears, sheet closes). Toast only on async results the user
  cannot see otherwise (background sync, webhook, scheduled export).

## 15. Modals + drawers — decision table

| Use a **Sheet** (drawer) for       | Use a **Dialog** (modal) for         |
|---|---|
| Create / edit forms with > 2 fields | Confirmation of destructive actions |
| Multi-section settings             | Single-question confirmations        |
| Slide-over detail panels           | Alerts before risky operations       |
| Anything with > ~6 vertical fields | Anything ≤ ~4 vertical fields        |

Both come from `@/components/ui/sheet` and `@/components/ui/dialog`.
Never use both for the same action.

## 16. Permissions

- Permissions hook: `usePermission('customers.write')` from
  `@/features/auth/use-permission`.
- Pattern:
  ```tsx
  const canWrite = usePermission('customers.write');
  return canWrite ? <Button>Edit</Button> : null;


---

## 17. Accessibility

```markdown
## 17. Accessibility

Radix Primitives (under shadcn) provide most of this for free:
focus trapping in dialogs, escape-to-close, ARIA roles, keyboard nav for
menus and tabs. The codebase's responsibility is the rest.

- **Labels**: every form control has an associated `<FormLabel>`. Icon-only
  buttons require `aria-label`.
- **Focus ring**: never `outline-none` without a `focus-visible:ring-*`
  replacement. The default focus utility on shadcn Buttons is correct;
  do not override.
- **Colour contrast**: text-on-bg pairs in the semantic-token table (Section 2b)
  are pre-tested for AA. Do not invent new pairs without re-testing.
- **Hit targets**: minimum `h-9` (36px) for interactive elements. `h-8`
  (32px) is the floor inside dense tables, never on top-level CTAs.
- **Motion**: `prefers-reduced-motion` is respected by Tailwind's
  `motion-safe:` / `motion-reduce:` variants. Wrap any non-essential
  animation in `motion-safe:`.

## How AI agents use this file

1. **Before writing any UI code**, read this file in full.
2. If you need a colour, spacing, or radius value, check Sections 2–6 first.
3. If you need a component, check Section 7. Use the shadcn primitive in
   `src/components/ui/`; do not reinvent.
4. If a token, utility, or variant you need isn't documented here,
   **propose adding it** before reaching for an arbitrary value.
5. When you finish a UI change, run the lint greps in Section 10 against your diff.
6. Reference the canonical pages cited at the bottom of Section 8 before writing
   a list, sheet, or detail page from scratch.

Cross-reference:
- `architecture/folder-structure.md` — where files go.
- `architecture/styleguide.md` — how to author Tailwind (CVA vs inline,
  when `@apply` is allowed, `cn()` semantics).
- `prompts/list-page.md` — list-page recipe.
- `prompts/sheet-form.md` — sheet-form recipe.

This file is referenced from `CLAUDE.md` so future sessions auto-load it.
