What to Put in design.md: A Complete Template
A good design.md is a decision document, not a style guide. If a senior designer left tomorrow, would the next person make the same calls?
If you’ve read Part 2 of the series, you know design.md is one of the four canonical docs an agent-ready codebase needs. It’s also the one most teams get wrong.
The common mistakes:
- They write a style guide (how to author CSS) instead of a design system memory (what the system is).
- They write a showcase (here are all the buttons we have) instead of a decision document (here’s when to use which button).
- They write values without semantics (
primary.main = #143666) without ever explaining when to reach forprimaryoversecondary. - They make it encyclopedic instead of opinionated — listing every component without ever saying which is canonical.
A good design.md is the answer to: “If a senior designer left tomorrow and the only thing the next person had was this file, would they make the same calls?”
This post is a complete annotated template. Steal everything.
Frontmatter — what to put at the top
# project-name — design.md
> Canonical design memory. Every AI session and human contributor reads this
> **before** writing UI. If a value isn't here, propose it as an addition
> before using it inline.
**Last updated**: YYYY-MM-DD
**Scope**: `src/` (or the specific app/package).
**Source of truth for values**: list the files that contain the actual tokens
(`src/assets/colors/colors.ts`, `src/theme/*`). This file documents how to
*use* them; never duplicate a hex value here without a corresponding token
in the source of truth.That last sentence matters. If your design.md lists hex values that aren’t in your colors.ts, it will drift the moment someone changes a token. Always reference the source file by path; let the file be the truth.
Section 1: Brand
## 1. Brand
| Surface | Value |
|---|---|
| Product | one-line product description |
| Audience | who this is for |
| Wordmark | how the name appears |
| Voice | how the product talks (3–5 traits, with bans) |
| References we draw from | 2–3 products we deliberately resemble |
| References we **avoid** | 2–3 we deliberately don't resemble |The “avoid” row is doing more work than the “draw from” row. It tells the agent which design priors to suppress — Material Design demo defaults, Bootstrap, Salesforce Lightning, generic SaaS gradient backgrounds. Without this, the agent reaches for whatever’s most common in its training data.
Section 2: Colour
This is the section your agent will reference most often. Spend the most words here.
2a. The principle (one paragraph)
All colours are tokens exported from `src/assets/colors/colors.ts` and
wired into the theme via `src/theme/palette.ts`. **Never hardcode hex
values.** Import the token namespace and reference the field.Then a ✅ / ❌ code block showing the correct pattern. Two lines each.
2b. The brand palette (with semantics, not just hex)
Don’t just dump the colour table. For each colour, tell the agent when to use it:
**Primary — navy** (`assets/colors.primary`).
Used for navigation chrome, headlines, the contained-secondary button.
| Token | Hex | Use |
|---|---|---|
| `primary.main` | #143666 | nav chrome, headlines, contained-secondary bg |
| `primary.dark` | #0C2043 | borders on contained-secondary, hover-darker chrome |
| `primary.light` | #596F96 | de-emphasised navy text |The “Use” column is the whole point. Without it, the agent guesses based on token name — which means it picks based on training-data priors about what “primary.main” usually means in React+MUI codebases. That’s wrong in your codebase ~30% of the time.
2c. Inverted conventions — call them out explicitly
Every codebase has one of these. The places where your convention is the opposite of the framework default. Examples I’ve encountered:
- The “primary” button colour is amber, not the primary palette.
- “Dark” variant is lighter than “main” (a real example from a real
colors.ts). - “Secondary” namespace contains a blue colour.
Call these out in a callout block. Not buried in the table. Not in a sub-bullet. A standalone ”⚠ Convention” block:
> ⚠ **Critical convention**: in MUI's button theme (`src/theme/button.ts`),
> `containedPrimary` renders with **secondary (amber)** as the background
> and **primary (navy)** as the text. This is intentional — amber is the
> most committal action. `containedSecondary` is the navy button.Every model trained on standard MUI will get this wrong. The callout costs nothing and saves hours of “the agent made the wrong button colour.”
2d. Quick-rules list
After the tables, summarise the rules an agent will apply hundreds of times:
### Colour use — quick rules
- **Primary CTA on any surface**: amber `containedPrimary`. Exactly one per surface.
- **Secondary CTA**: navy `containedSecondary`.
- **Status communication**: use `success`, `warning`, `error`, `info` — never grey or the brand pair.
- **Body copy links**: `primary.main`. Never accent blues for links.
- **Tables, filters, page chrome**: neutral `grey.*` tokens.
- **Gradients**: onboarding / marketing only — never on data UI.These rules are what an agent will reach for during 90% of tasks. Put them in a compact list, not in prose.
Section 3: Typography
Keep this short. Most projects need ~80 words plus a table.
## 3. Typography
**Font family**: Roboto. Fallback: `ui-sans-serif, system-ui, sans-serif`.
**Scale** — defined in `src/theme/typography.ts`. Use the MUI `<Typography
variant="…">` wrapper or the atoms `Typography`; never hand-roll font sizes
inline.
| Variant | Size | Weight | Use |
|---|---|---|---|
| `h5` | 1.5rem | 400 | page H1 (list page title, detail name) |
| `h6` | 1.25rem | 500 | section H2 |
| `subtitle1` | 1rem | 500 | card / drawer titles |
| `subtitle2` | 0.875rem | 500 | dense card titles, table-section headers |
| `body2` | 0.875rem | 400 | **default body** — table rows, form fields |
| `caption` | 0.75rem | 400 | metadata, timestamps, helper text |
| `overline` | 0.75rem | 400 | uppercase section labels |
**Weights**: 400, 500. **No 600, no 700** for body — bold uses weight 500
with darker colour, not heavier weight.
**Tabular numbers**: money, quantity, and count columns must use
`font-variant-numeric: tabular-nums`. Non-negotiable for any table with
amounts.The “default body” annotation and the “no 600” rule are the highest-leverage lines. Without them, agents pick from the full MUI variant set seemingly at random.
Section 4: Spacing
## 4. Spacing
Use MUI's spacing scale via `sx`/`styled` — `theme.spacing(n)` where
`n * 8 = px`. Prefer the scale to magic px values.
| MUI value | Px | Use |
|---|---|---|
| `0.5` | 4 | tightest gap (chip internal padding) |
| `1` | 8 | dense table cells, small button padding |
| `2` | 16 | card sections, form rows |
| `3` | 24 | page header padding, dialog padding |
| `4` | 32 | large section gaps |
**Standard gaps**:
- Between cards / form sections: `gap: 3` (24px)
- Between fields inside a form: `gap: '20px'`
- Inline elements (icon + label): `gap: 1` (8px)If your spacing scale has 30+ values, your design system is too forgiving. Pick 6–8 and ban the rest.
Section 5: Borders, radius, shadows
Three short sections.
## 5. Borders + radius
- **Default border**: `1px solid ${grey.g200}` (visible separators on white)
- **Subtle inner divider**: `1px solid ${grey.g100}`
- **Component border** (inputs, outlined buttons): `1px solid ${other.border}`
**Radius scale**:
| Value | Use |
|---|---|
| `4px` | inputs, buttons (MUI default), chips |
| `8px` | table containers, small cards |
| `12px` | drawer content cards, form wrapper cards |
| `9999px` / `50%` | avatars, status dots, pill chips |
## 6. Shadows
MUI's default elevation scale is largely **not used**. Surfaces are flat
on a light grey field. Reserved usages:
- `theme.shadows[1]` — primary CTAs, cards on tinted bg
- `theme.shadows[2]` — dropdowns, autocomplete popovers
- `theme.shadows[4]` — dialogs, drawers (MUI default)
**No glow shadows. No coloured shadows on data UI.**Notice: “what we don’t use” is part of the documentation. Agents will reach for theme.shadows[8] if you don’t actively tell them you’ve capped at 4.
Section 6: Components — usage rules
This is the longest section. Structured per primitive, with the same shape each time:
### Button (`components/atoms/Button`)
```tsx
import Button from 'components/atoms/Button';
<Button variant="contained" color="primary" size="small">Save</Button>Variant + colour decoder (because MUI’s color naming is inverted here):
| Variant | Color | Visual | When |
|---|---|---|---|
contained | primary | Amber bg, navy text | single most committal action |
contained | secondary | Navy bg, white text | second-priority action |
contained | error | Red bg, white text | destructive (Delete, Disconnect) |
outlined | primary | Amber border, amber text | non-committal alt to amber |
outlined | secondary | Navy border, navy text | de-emphasised alt to navy |
text | primary | Amber text, transparent | tertiary inline (Clear, Reset) |
One amber-contained button per surface. Multiple amber CTAs dilute the hierarchy.
Three things to notice:
1. **Import path is shown.** No agent has to guess.
2. **The variant table has a "When" column.** This is where the design memory lives.
3. **The constraint at the bottom** ("one per surface") is the rule that makes the system coherent.
Repeat this shape for every primitive: `Typography`, form fields, `Chip`, `Avatar`, `Table`, `Drawer`, `Dialog`, `Popover`, `EmptyState`, `Skeleton`. ~10–15 sections total.
For form fields specifically, include a **decision table**:
```markdown
| Scenario | Component | Path |
|---|---|---|
| Text / textarea | `FormTextField` | `components/molecules/FormTextField` |
| Single select | `MuiAutocomplete` | `components/molecules/MuiAutocomplete` |
| Checkbox | `FormCheckbox` | `components/molecules/FormCheckbox` |
| Toggle | `FormSwitchInput` | `components/atoms/FormSwitchInput` |
| Number / currency | `FormDecimalControlledField` | `components/atoms/FormDecimalControlledField` |
| Date picker | `FormDatePicker` | `components/molecules/FormDatePicker` |Every “scenario” gets exactly one row. If you have two valid components for “single select”, you don’t have a design system yet — you have a duplicate to resolve.
Section 7: Layout patterns
ASCII diagrams plus contracts. Three patterns minimum: list page, drawer form, detail page.
### List page
┌──────────────────────────────────────────┐ │ Module Name │ Portal → top-bar ├──────────────────────────────────────────┤ │ [search] [Filter] [+ Create]│ filter bar inside Box id=HEADER_ID │ Tab strip │ tabs inside same Box ├──────────────────────────────────────────┤ │ ☐ Col1 Col2 Col3 … ⋮ │ MRT header ├──────────────────────────────────────────┤ │ …rows… │ ├──────────────────────────────────────────┤ │ N of total [pagination] │ TableFooter └──────────────────────────────────────────┘
- Filter bar + tabs **both inside** `<Box id={HEADER_ID}>` so dynamic height measures them together.
- `tableHeight = calc(100vh - headerHeight - TABS_HEIGHT - TOP_TOOLBAR_HEIGHT - FOOTER_HEIGHT)`
- Header padding (typical): `pt: 2, px: 3, pb: 1`
- Actions column header background: `${grey.custom1} !important`The ASCII diagram is doing a lot of work. It’s not for show — the agent uses it to figure out which element goes where. Don’t skip it.
Each pattern needs a canonical reference path: “The reference implementation is pages/Settings/ResourceCostSheet/.” The agent will read it before writing.
Section 8: Loading + transitions
A short, opinionated section. Most teams overthink this.
## 9. Loading + transitions
### Rules
1. **Skeleton-match-layout**: skeletons match the exact dimensions and
positions of the content. Per-field, per-row, per-card.
2. **No centered full-page spinners** on list pages, forms, or detail pages.
3. **Optimistic mutations** where the API contract permits.
4. **Toast for async results**, not for user-initiated submits that already
produce a UI change (e.g., row disappears from list).
5. **Pre-fetch on hover** for navigation links.
### Banned
- ❌ Centered `<CircularProgress />` as the only loading state.
- ❌ "Loading..." text alone.
- ❌ Slide-in / slide-out route transitions.
- ❌ Animated success checkmarks that block the user.The “banned” list is the half that matters. Agents will produce any of those four by default unless you ban them explicitly.
Section 9: Anti-patterns (banned)
Don’t bury this. Put it near the end as its own section, with a ❌ for every entry. Agents are good at recognising patterns to avoid when they’re listed bluntly.
## 10. Anti-patterns (banned)
- ❌ **Hardcoded hex values.** Import from `assets/colors`.
- ❌ **Barrel imports.** `from 'components/atoms/Button'` — never `'atoms'`.
- ❌ **TypeScript escape hatches.** No `any`, `as any`, `@ts-ignore`.
- ❌ **Inline `sx={{...}}` objects** in component files. Move to sibling `style.ts`.
- ❌ **Two `containedPrimary` buttons** on the same surface. Pick one.
- ❌ **Raw MUI components** in page modules. Use atoms/molecules wrappers.
- ❌ **`enum` for new code.** Use `const` objects with `as const`.
- ❌ **Default exports** in component files. Named exports only.
- ❌ **Cross-module imports.** Never import from `pages/AnotherModule/`.
- ❌ **MUI icon barrel imports.** Pulls the entire icon bundle.12–15 entries is the right number. More and the agent loses track; fewer and you’ve under-specified.
Section 10: Forms, toasts, modals — the “narrow rules” sections
Each of these gets ~10 lines. They cover the patterns that show up in every project:
## 12. Form patterns
- **Validation**: Zod schema in `utils/validation.ts`, exported with inferred type.
- **Required strings**: `z.string().min(1, '...')` — never `.nonempty()`.
- **Nullable selects**: `.nullable().refine(val => val !== null, …)`.
- **react-hook-form mode**: `'all'` (validate on blur + change).
- **Labels**: above the field, `caption` weight 500, `text.secondary`.
- **Required indicator**: red asterisk, `error.main`. No parenthesised "(required)".
- **Submit button**: bottom of form, amber `containedPrimary`.
- **Cancel button**: only when context demands.
## 14. Toasts
- Use the project's `useToast` hook. Position: bottom-right.
- Success: 2–3s. Error: 5s, may be sticky for actionable errors.
- One line. No headlines. No HTML.
- **Don't toast on direct user actions** that already produce a UI change.
## 15. Modals + drawers
| Use a **drawer** for | Use a **dialog** for |
|---|---|
| Create / edit forms with > 2 fields | Confirmation of destructive actions |
| Multi-section settings | Single-question confirmations |
| Slide-over detail panels | Alerts before risky actions |The drawer-vs-dialog table is one of the most-referenced sections of any design.md I’ve seen in practice. Agents reach for modals reflexively because their training data is full of them. The table re-balances them toward drawers, which is usually the right call for product UIs.
Section 11: How AI agents use this file
End the document with explicit instructions to the agent:
## How AI agents use this file
1. **Before writing any UI code**, read this file in full.
2. If you need a colour/size/spacing value, check sections 2–6 first.
3. If you need a component pattern, check section 7. Use the primitive;
don't reinvent.
4. If a value you need isn't documented here, **propose adding it** before
writing inline classes or hex codes.
5. When you finish a UI change, scan the diff for anti-patterns (section 10).
Cross-reference:
- `architecture/folder-structure.md` for where files go.
- `styleguide.md` for *how* to author styles (sx vs `styled()`).
- `prompts/tableMigration.md` for list-page migration.
- `prompts/formMigration.md` for form migration.
This file is referenced from `CLAUDE.md` so future sessions auto-load it.This section is doing two things:
- Telling the agent the order of operations (“read first, propose additions”).
- Pointing at other docs so the agent doesn’t try to put everything in
design.md.
What not to put in design.md
A design.md is a memory document, not a reference manual. Some things belong elsewhere:
- How to author styles (sx vs styled, TypeScript types for styles, file naming) →
architecture/styleguide.md. - Folder structure rules →
architecture/folder-structure.md. - Task-specific recipes (how to migrate a list page) →
docs/prompts/*.md. - Component prop documentation → the component source file’s JSDoc or a Storybook entry.
- Code samples longer than ~10 lines → the reference implementation in
src/, linked.
The test: if it’d be obvious to a human reader from looking at src/, it doesn’t belong in design.md. If it requires intent that can’t be inferred from the code, it does.
Length and rhythm
Target: 400–500 lines total. Anything shorter is probably missing the “when to use” semantics. Anything longer is probably encyclopedic.
Structure I use, in order:
- Frontmatter (~10 lines)
- Brand (~15)
- Colour (~120 — the longest section)
- Typography (~30)
- Spacing (~25)
- Borders + radius (~20)
- Shadows (~15)
- Components — usage rules (~150 — second longest)
- Layout patterns (~80)
- Loading + transitions (~30)
- Anti-patterns (~25)
- Empty states (~10)
- Form patterns (~15)
- Tables (specific) (~25)
- Toasts (~10)
- Modals + drawers (~15)
- Permission-aware rendering (~10)
- Accessibility (~15)
- How AI agents use this file (~15)
The numbers won’t match yours exactly. The ratio will. Spend most of your words on Colour and Components — those are the two surfaces an agent touches on every task.
Closing thought
The reason design.md is so high-leverage is the same reason MIGRATIONS.md is: it’s the document the agent reads when there’s no obvious answer in the code. Most other docs in a repo are about the code; design.md is about the intent behind the code.
You will write this once and update it 4–6 times a year. Each update will save your team and your agents tens of hours of “is this the right way?” guessing.
Start with the template above. Cut what you don’t need. Add the inverted conventions and the bans. Reference the source-of-truth files. Publish.
The next person to write a button in your codebase — human or model — will get it right on the first try.
Agent-ready React
6 parts in this series.
A six-part series on making legacy React codebases ready for AI coding agents.
- 01 Why Your Legacy React Codebase Confuses AI Coding Agents
- 02 A 3-Week Plan to Make Your Legacy React Codebase Agent-Ready
- 03 Rules That Agents Actually Follow: Enforcement Over Aspiration previous
- 04 What to Put in design.md: A Complete Template ← you are here
- 05 Writing Task-Specific Agent Prompts That Work First Try up next
- 06 Session-Start Hooks That Pay for Themselves
What did you take away?
Thoughts, pushback, or a story of your own? Drop a reply below — I read every one.
Comments are powered by Disqus. By posting you agree to their terms.
