design.md for an MUI Codebase: A Concrete Template

# product-name — design.md

> Canonical design memory. Every AI session and human contributor reads this
> **before** writing UI. If a value isn't here, propose it as an addition
> before using it inline.

**Last updated**: 2026-05-13
**Scope**: `src/` (the web app package).
**Source of truth for values**:
- `src/assets/colors/colors.ts` — hex tokens (primary, accent, status, grey scale).
- `src/theme/palette.ts` — MUI palette wiring.
- `src/theme/typography.ts` — variant scale.
- `src/theme/components/*.ts` — per-component variant overrides
  (`Button.ts`, `TextField.ts`, `Chip.ts`, …).
- `src/theme/index.ts` — `createTheme` composition.

This file documents how to *use* the tokens; it never duplicates a hex
value without a corresponding token in the source of truth.

## 1. Brand

| Surface | Value |
|---|---|
| Product | <one-line product description> |
| Audience | <who this is for — be specific; not "everyone"> |
| Wordmark | <how the name appears: case, spacing, em-dash rules> |
| Voice | <3–5 traits, e.g. "direct, technical, no exclamation marks"> |
| References we draw from | <2–3 products we deliberately resemble> |
| References we **avoid** | Material Design demos, Bootstrap, Salesforce Lightning, generic SaaS gradient hero pages |

All colours are hex tokens exported from `src/assets/colors/colors.ts` and
wired into the MUI palette via `src/theme/palette.ts`. **Never hardcode
hex values in component files.** Import the token namespace:

✅ `import { colors } from 'assets/colors';` then `colors.primary.main`.
✅ Inside `sx`: `sx={{ color: 'primary.main' }}` — resolves through the theme.
❌ `sx={{ color: '#1E40AF' }}`
❌ `style={{ backgroundColor: '#1E40AF' }}`

**Primary — deep blue** (`colors.primary`). Used for navigation chrome,
headlines, the contained-secondary button background, link text.

| Token            | Hex      | Use |
|---|---|---|
| `primary.main`   | #1E40AF  | nav chrome, page headlines, contained-secondary bg, body links |
| `primary.dark`   | #1E3A8A  | hover-darker on chrome, contained-secondary border on hover |
| `primary.light`  | #3B82F6  | de-emphasised primary text, selected-row highlight |
| `primary.contrastText` | #FFFFFF | text on `primary.main` surfaces |

**Accent — warm amber-orange** (`colors.accent`). The most committal action
on any surface. Used **only** as a CTA colour — never on chrome, never on
body text, never on chart fills.

| Token            | Hex      | Use |
|---|---|---|
| `accent.main`    | #EA580C  | contained-primary bg, primary CTA in dialogs/drawers |
| `accent.dark`    | #C2410C  | hover/active for primary CTAs |
| `accent.light`   | #FB923C  | focus ring on contained-primary |
| `accent.contrastText` | #FFFFFF | text on `accent.main` |

**Status palettes** (`colors.error`, `colors.warning`, `colors.success`, `colors.info`):

| Palette  | main    | dark    | light   | Use |
|---|---|---|---|---|
| `error`  | #DC2626 | #991B1B | #FCA5A5 | destructive actions, required-field asterisk, validation errors |
| `warning`| #D97706 | #92400E | #FCD34D | non-blocking warnings, "needs attention" chips |
| `success`| #16A34A | #15803D | #86EFAC | success toasts, completed-state chips |
| `info`   | #0284C7 | #075985 | #7DD3FC | informational banners, neutral-status chips |

**Grey scale** (`colors.grey`). Eleven steps; we use seven.

| Token        | Hex      | Use |
|---|---|---|
| `grey.50`    | #F9FAFB  | page background |
| `grey.100`   | #F3F4F6  | table zebra, hovered row, disabled bg |
| `grey.200`   | #E5E7EB  | default border (`1px solid`) |
| `grey.300`   | #D1D5DB  | input border, divider on tinted bg |
| `grey.500`   | #6B7280  | secondary text, helper text, placeholders |
| `grey.700`   | #374151  | body text (`body2` default colour) |
| `grey.900`   | #111827  | headlines, emphasised body |

Banned greys: `grey.400`, `grey.600`, `grey.800` — we do not use them. If
you reach for one, you're picking a value that doesn't have a documented
role.

> ⚠ **Critical convention**: in `src/theme/components/Button.ts`, the
> `containedPrimary` variant renders with the **accent** palette as the
> background and primary-on-white text — *inverted* from what MUI's
> default palette wiring suggests. This is intentional: the accent is the
> most committal action on any surface. `containedSecondary` is the
> plain-primary-blue button.
>
> This is the single most-violated rule by AI agents working in this
> codebase. The model's training-data prior says `containedPrimary` is the
> brand primary colour; in this codebase, it is the brand accent.

- **Primary CTA on any surface**: `<Button variant="contained" color="primary">` — renders accent-orange. Exactly **one per surface**.
- **Secondary CTA**: `<Button variant="contained" color="secondary">` — renders primary-blue.
- **Destructive**: `<Button variant="contained" color="error">`.
- **Status communication**: `success`, `warning`, `error`, `info` — never `grey` and never the brand pair for status.
- **Body copy links**: `primary.main`. Never accent.
- **Tables, filters, chrome**: `grey.*` tokens only.
- **Gradients**: onboarding / marketing surfaces only. Never on data UI.

## 3. Typography

**Font family**: Inter. Fallback: `ui-sans-serif, system-ui, sans-serif`.
Loaded from `src/assets/fonts/inter/` and wired into `theme.typography.fontFamily`.

**Scale** — defined in `src/theme/typography.ts`. Use MUI's
`<Typography variant="…">` (or the project's `atoms/Typography` wrapper).
Never hand-roll `fontSize` inline.

| Variant     | Size      | Weight | Line-height | Use |
|---|---|---|---|---|
| `h1`        | 2.5rem    | 500    | 1.2  | reserved — marketing only |
| `h2`        | 2rem      | 500    | 1.25 | reserved — marketing only |
| `h3`        | 1.75rem   | 500    | 1.3  | reserved — marketing only |
| `h4`        | 1.5rem    | 500    | 1.33 | page H1 (list-page title, detail-page name) |
| `h5`        | 1.25rem   | 500    | 1.4  | section H2 (drawer title, dialog title) |
| `h6`        | 1.125rem  | 500    | 1.45 | card title, table-section header |
| `subtitle1` | 1rem      | 500    | 1.5  | dense card title, popover header |
| `subtitle2` | 0.875rem  | 500    | 1.55 | form-section label, drawer subsection |
| `body1`     | 1rem      | 400    | 1.5  | reserved — long-form content (rare in app shell) |
| `body2`     | 0.875rem  | 400    | 1.55 | **default body** — table rows, form fields, dialog body |
| `caption`   | 0.75rem   | 400    | 1.6  | metadata, timestamps, helper text under inputs |
| `overline`  | 0.75rem   | 500    | 1.6  | uppercase section labels (`letter-spacing: 0.08em`) |

**Weights**: 400, 500. **No 600, no 700** for body text — emphasis uses
weight 500 with `grey.900` colour, not heavier weight.

**Tabular numbers**: any money, quantity, count, or duration column must
use `font-variant-numeric: tabular-nums`. The `atoms/MoneyCell` and
`atoms/NumberCell` wrappers handle this; do not roll your own.

## 4. Spacing

MUI's spacing scale: `theme.spacing(n)` where `n * 8 = px`. Use the scale
via `sx`, `styled`, or `Box` shorthand — never magic px values.

| `theme.spacing` | Px | Use |
|---|---|---|
| `0.5` | 4   | tightest gap (chip internal padding, icon-text gap in dense cells) |
| `1`   | 8   | dense table cells, small button padding, inline icon+label |
| `2`   | 16  | card sections, form rows, default card padding |
| `3`   | 24  | page-header padding, dialog content padding, form-section gap |
| `4`   | 32  | large section gaps on detail pages |
| `6`   | 48  | empty-state vertical padding |
| `8`   | 64  | marketing surfaces only |

**Standard gaps**:
- Between cards / form sections: `gap: 3` (24px)
- Between fields inside a form: `gap: 2.5` (20px) — written as `gap: '20px'` is also acceptable; both compile to the same value
- Inline elements (icon + label): `gap: 1` (8px)
- Page-header padding: `pt: 2, px: 3, pb: 1`

Banned values: `theme.spacing(5)`, `theme.spacing(7)`, and any
ad-hoc `mt="13px"` style props. Pick from the table or propose an
addition.

## 5. Borders + radius

- **Default visible separator** (on white): `1px solid ${grey.200}`
- **Subtle inner divider** (between rows in a card): `1px solid ${grey.100}`
- **Component border** (inputs, outlined buttons): `1px solid ${grey.300}`
- **Hover border on outlined**: `1px solid ${primary.main}`
- **Focus border on inputs**: `2px solid ${primary.main}` (via MUI default outline behaviour)

**Radius scale** (`theme.shape.borderRadius` defaults to 4):

| Value | Use |
|---|---|
| `4px`  | inputs, buttons, chips (MUI default) |
| `8px`  | table containers, small cards, popovers |
| `12px` | drawer content cards, form wrapper cards, dialog surfaces |
| `9999px` | avatars, status dots, pill chips |

`16px` and above are banned outside marketing surfaces.

## 6. Shadows

MUI's `theme.shadows[0..24]` is largely **not used**. App surfaces are
flat on a `grey.50` field. Reserved usages:

- `theme.shadows[1]` — primary CTAs on tinted backgrounds, hovered cards.
- `theme.shadows[2]` — autocomplete popovers, menu, popover.
- `theme.shadows[4]` — dialogs, drawers (MUI default for both).

Banned: `theme.shadows[3]`, `theme.shadows[5..24]`. No coloured shadows.
No glow effects. No `box-shadow: inset` on data UI.

### Button (`components/atoms/Button`)

```tsx
import { Button } from 'components/atoms/Button';

<Button variant="contained" color="primary" size="medium">Save</Button>


### Typography

```markdown
### Typography (`components/atoms/Typography`)

```tsx
import { Typography } from 'components/atoms/Typography';

<Typography variant="body2" color="text.secondary">Last updated 2 hours ago</Typography>


### Form fields

```markdown
### Form fields

Decision table. One row per scenario; one component per row.

| Scenario | Component | Path |
|---|---|---|
| Single-line text / textarea | `FormTextField` | `components/molecules/FormTextField` |
| Number / currency           | `FormDecimalField` | `components/molecules/FormDecimalField` |
| Single-select (≤ 10 options)| `FormSelect`    | `components/molecules/FormSelect` |
| Single-select (searchable)  | `FormAutocomplete` | `components/molecules/FormAutocomplete` |
| Multi-select                | `FormMultiAutocomplete` | `components/molecules/FormMultiAutocomplete` |
| Checkbox (single)           | `FormCheckbox`  | `components/molecules/FormCheckbox` |
| Radio group                 | `FormRadioGroup`| `components/molecules/FormRadioGroup` |
| On/off toggle               | `FormSwitch`    | `components/atoms/FormSwitch` |
| Date picker                 | `FormDatePicker`| `components/molecules/FormDatePicker` |
| Date range                  | `FormDateRange` | `components/molecules/FormDateRange` |
| File upload                 | `FormFileUpload`| `components/molecules/FormFileUpload` |

All wrappers are RHF-aware: they accept `name` + the form's `control` and
wire up validation, error display, and required-asterisk rendering. **Do
not** drop down to `<TextField>` / `<Autocomplete>` from `@mui/material`
inside a page module. If a scenario isn't in the table, add a row before
writing the component inline.

### Chip (`components/atoms/StatusChip`, `components/atoms/Chip`)

| Use case | Component | Props |
|---|---|---|
| Status communication | `StatusChip` | `status="success" \| "warning" \| "error" \| "info" \| "neutral"` |
| Filter / removable tag | `Chip` (MUI) via `atoms/Chip` wrapper | `onDelete` for removable |
| Read-only metadata pill | `atoms/Chip` | `variant="outlined"` |

**Never** colour a chip outside the five status values for status
communication. Custom-colour chips on data tables = visual noise.

### Avatar (`components/atoms/Avatar`)

- Sizes: 24 (table-cell), 32 (default), 40 (drawer header), 64 (detail page).
- Fallback: user initials, `grey.200` bg, `grey.700` text.
- Image avatars: `loading="lazy"`. Never block render on avatar fetch.
- Never use `<img>` directly for user photos — always `atoms/Avatar`.

### Table — TanStack Table v8 (`components/organisms/DataTable`)

We use **TanStack Table** for headless logic + MUI primitives for chrome.
No `@mui/x-data-grid`. Reference implementation: `pages/Customers/CustomersList/`.

```tsx
import { DataTable } from 'components/organisms/DataTable';

<DataTable
  columns={customerColumns}
  data={customers}
  pagination={{ pageSize: 50 }}
  onRowClick={openDetail}
  isLoading={query.isLoading}
/>


### Drawer

```markdown
### Drawer (`components/molecules/Drawer`)

Anchored right. Widths: `sm` (480px), `md` (640px, default), `lg` (840px).

```tsx
<Drawer open={open} onClose={close} width="md" title="Edit customer">
  <DrawerBody>…fields…</DrawerBody>
  <DrawerFooter>
    <Button variant="text" color="secondary" onClick={close}>Cancel</Button>
    <Button variant="contained" color="primary" type="submit">Save</Button>
  </DrawerFooter>
</Drawer>


### Dialog

```markdown
### Dialog (`components/molecules/Dialog`)

For confirmations and single-question prompts only. **Not for forms** —
those go in drawers.

```tsx
<Dialog open={open} onClose={close} title="Delete invoice?" severity="error">
  <DialogBody>This action cannot be undone.</DialogBody>
  <DialogFooter>
    <Button variant="text" color="secondary" onClick={close}>Cancel</Button>
    <Button variant="contained" color="error" onClick={confirm}>Delete</Button>
  </DialogFooter>
</Dialog>


### Popover

```markdown
### Popover (`components/molecules/Popover`)

For lightweight contextual UIs: column-filter pickers, share-link
popovers, kebab-menu surfaces. Anchored to the trigger element.

- Max width: 360px.
- No forms with > 3 fields. Promote to a drawer.
- Closes on outside-click, Escape, or scroll of the underlying surface.

### EmptyState (`components/molecules/EmptyState`)

```tsx
<EmptyState
  illustration="no-customers"
  title="No customers yet"
  description="Add your first customer to start invoicing."
  action={<Button variant="contained" color="primary">Add customer</Button>}
/>


### Skeleton

```markdown
### Skeleton (`components/atoms/Skeleton`)

Matches the **exact** dimensions of the content it replaces. Per-field,
per-row, per-card.

- `variant="text"` for inline text.
- `variant="rectangular"` for cards / blocks.
- `variant="circular"` for avatars / dots.

Never a centred `<CircularProgress />` on list pages, forms, or detail
pages.

### List page



- Filter bar + tabs **both inside** `<Box id={HEADER_ID}>` so the dynamic
  height measures them together.
- `tableHeight = calc(100vh - headerHeight - TABS_HEIGHT - TOP_BAR_HEIGHT - FOOTER_HEIGHT)`.
- Header padding: `pt: 2, px: 3, pb: 1`.
- Actions-column header bg: `grey.100`.
- Reference implementation: `pages/Customers/CustomersList/`.

### Drawer form



- Header: `<Typography variant="h5">`, divider below.
- Sections: `<Typography variant="subtitle2">`, `mb: 2`.
- Field gap: `gap: 2.5`.
- Footer: `Cancel` (text + secondary), `Save` (contained + primary, accent).
- Reference: `pages/Customers/CustomerDrawerForm/`.

### Detail page



- Two-column summary uses MUI `Box` with `display: 'grid'`,
  `gridTemplateColumns: { xs: '1fr', md: '1fr 1fr' }`, `gap: 3`.
- Never `Grid container` — we use CSS Grid via `Box` for predictability.
- Reference: `pages/Customers/CustomerDetail/`.

## 9. Loading + transitions

### Rules

1. **Skeleton-match-layout**: skeletons match the exact dimensions and
   positions of the content. Per-field, per-row, per-card.
2. **No centered full-page spinners** on list pages, forms, or detail pages.
3. **Optimistic mutations** via TanStack Query's `onMutate` where the API
   contract permits (idempotent endpoints, predictable response shape).
4. **Toast for async results**, not for user-initiated submits that
   already produce a UI change (row disappears, drawer closes, etc.).
5. **Prefetch on hover** for navigation links via TanStack Query's
   `prefetchQuery`.

### Banned

- ❌ Centered `<CircularProgress />` as the only loading state.
- ❌ "Loading..." text alone.
- ❌ Slide-in / slide-out route transitions (use MUI's default `Fade` or none).
- ❌ Animated success checkmarks that block the user.
- ❌ Backdrop spinners on mutation. Use button-level loading state instead.

## 10. Anti-patterns (banned)

- ❌ **Hex literals outside `src/assets/colors/colors.ts`.** Including in `sx`, `styled`, `style`, theme overrides, SVG inline `fill`.
- ❌ **Direct `@mui/material/X` imports in page modules.** Always go through `components/atoms/X` or `components/molecules/X`. The wrappers exist to encode this codebase's conventions; bypassing them re-introduces the drift.
- ❌ **Inline `sx={{ … }}` objects with more than 3 keys.** Move to a sibling `style.ts` exporting a typed `SxProps<Theme>` constant.
- ❌ **`MuiButton-root` / `.MuiOutlinedInput-root` class overrides** in component CSS. Use `theme.components.MuiButton.styleOverrides` in `src/theme/components/Button.ts` instead.
- ❌ **Barrel imports from `@mui/icons-material`.** `import { ChevronDown, Trash } from '@mui/icons-material'` pulls the entire icon bundle. Use the per-icon entry point: `import ChevronDown from '@mui/icons-material/ChevronDown'`.
- ❌ **TypeScript escape hatches.** No `any`, no `as any`, no `@ts-ignore`, no `@ts-nocheck`.
- ❌ **Default exports** in component files. Named exports only — they grep better and tooling renames them safely.
- ❌ **Cross-module imports.** Never `import` from `pages/AnotherModule/`. Shared logic goes to `components/` or `utils/`.
- ❌ **Two `containedPrimary` buttons on the same surface.** Pick one. The whole hierarchy collapses if there are two.
- ❌ **`enum` for new code.** Use `const` objects with `as const` and a derived union type.
- ❌ **`@mui/material/Grid` `container`/`item` syntax.** Use `Box` with `display: 'grid'` (see Section 8 detail page).
- ❌ **Inline `useState` for form fields.** Forms go through react-hook-form (Section 13).
- ❌ **Direct `fetch()` / `axios` in components.** All server state through TanStack Query hooks in `features/<domain>/queries.ts`.
- ❌ **`<img>` for user-uploaded media.** Use `atoms/Avatar` or `atoms/Image` (which handles lazy-load + fallback).
- ❌ **`zIndex` literals.** Use `theme.zIndex.appBar | drawer | modal | snackbar | tooltip` only.

## 11. Empty states

Every list, every tab, every table gets an empty state. None of:
"no data found", a sad-face icon, or a blank surface.

Structure:
- Illustration (from `assets/illustrations/`)
- Title (`subtitle1`, `grey.900`)
- Description (`body2`, `grey.500`, 1–2 sentences max)
- Primary action button (when relevant)

Use `components/molecules/EmptyState` — see Section 7 Components.

Two flavours:
- **First-time empty** (user has none of X yet): action present, copy invites creation.
- **Filter-empty** (search/filter returned no matches): action is "Clear filters", copy says no matches.

## 12. Form patterns

- **Validation**: Zod schemas live in `features/<domain>/schemas.ts`,
  exported alongside the inferred type:
  ```ts
  export const customerSchema = z.object({ … });
  export type CustomerForm = z.infer<typeof customerSchema>;


---

## 13. Tables (specific)

```markdown
## 13. Tables — specific rules

- **Selection column**: leftmost, `width: 48px`, checkbox-only, no header label.
- **Actions column**: rightmost, `width: 56px`, kebab icon button, header bg `grey.100`.
- **Money columns**: right-aligned, `MoneyCell` wrapper (tabular-nums, currency-aware).
- **Date columns**: left-aligned, `DateCell` wrapper (relative ≤ 7 days, ISO date beyond).
- **Status columns**: `StatusChip`, no raw text.
- **Empty cell**: render `—` (em-dash, `grey.500`), never empty string or `null`.
- **Row hover**: `grey.50` bg, `cursor: pointer` only if the row is clickable.
- **Selected row**: `primary.light` bg at 20% alpha (`alpha(primary.light, 0.2)`).
- **Sticky header**: always. Sticky first column only when ≥ 6 columns visible.
- **Column resize**: enabled for text columns, disabled for fixed-width (selection, actions, status).
- **Pagination**: server-side for ≥ 1k rows; client-side acceptable below.

## 14. Toasts

Use the project's `useToast` hook (`features/toast/useToast.ts`).
Backed by `notistack` under the hood; do not call notistack directly.

- Position: bottom-right.
- Success: 3s. Info: 4s. Warning: 5s. Error: sticky until dismissed if actionable, 6s otherwise.
- One line. No headlines. No HTML, no links inside the message (use the `action` slot for an actionable button).
- **Don't toast on direct user actions** that already produce a UI change (row disappears, drawer closes, chip flips state).
- **Do toast on background results**: optimistic mutation reconciliation, server-pushed events, post-navigation outcomes.

## 15. Modals + drawers

| Use a **drawer** for | Use a **dialog** for |
|---|---|
| Create / edit forms with > 2 fields | Confirmation of destructive actions |
| Multi-section settings | Single-question confirmations |
| Slide-over detail panels with their own scroll | Alerts before risky actions |
| Anything the user might want to keep open while comparing | Anything that must block until answered |

Default to drawer. Reach for dialog only when the action is **blocking
and binary**.

## 16. Permission-aware rendering

- Use `usePermissions()` from `features/auth/usePermissions.ts`.
- Hide actions the user cannot perform; do not render them disabled. (Exception: bulk-action toolbars in tables, where disabled communicates "select rows first" — not a permission state.)
- For routes: the route guard handles redirect; do not duplicate permission checks at the page level.
- For sections within a page that may be partially permitted: render the section with a `<PermissionGate permission="…">` wrapper. The gate renders nothing when denied; never an "Access denied" placeholder mid-page.

## 17. Accessibility

- Every interactive element has a visible label or an `aria-label`. Icon-only buttons → `aria-label` required.
- Focus ring: MUI default. Never `outline: none` without a replacement.
- Forms: every input has a `<label>` (the `Form*` wrappers handle this).
- Dialogs / drawers: focus traps via MUI defaults — never disable. Initial focus on the first interactive element.
- Colour contrast: body text ≥ 4.5:1 against background. The grey scale in Section 2 is contrast-checked against `grey.50` and white.
- Motion: respect `prefers-reduced-motion`. The `useReducedMotion` hook returns the user's preference; gate non-essential transitions behind it.
- Keyboard: tab order follows visual order. Skip link at the top of every page jumps to `<main id="main">`.

## 18. How AI agents use this file

1. **Before writing any UI code**, read this file in full. It is short on
   purpose.
2. If you need a colour / size / spacing value, check Section 2–6 first. If the
   value isn't here, check the source-of-truth file listed in the
   frontmatter. If it isn't there either, **propose adding it** before
   writing inline.
3. If you need a component pattern, check Section 7. Use the existing primitive
   from `components/atoms` or `components/molecules`; do not reinvent.
4. For a list page, drawer form, or detail page, read the reference
   implementation linked in Section 8 before writing.
5. When you finish a UI change, scan the diff against Section 10 (anti-patterns).
   Every `❌` is a blocker.

Cross-references (other docs in this repo):

- `architecture/folder-structure.md` — where new files go.
- `architecture/styleguide.md` — *how* to author styles (`sx` vs `styled()`, file naming).
- `prompts/listPageMigration.md` — recipe for migrating an old list page.
- `prompts/formMigration.md` — recipe for migrating a form to RHF + Zod.

This file is referenced from `CLAUDE.md` so future sessions auto-load it.
